Commercial Refrigeration Motor, 115-230V, CCW OSE, 1550-1725RPM, 4HP-25W EC5412E

❄️ Commercial Refrigeration ECM Motor | Replaces US‑Nidec® EC5412E / S59‑572

Brand new commercial refrigeration motor replacing US‑Nidec part numbers EC5412E, S59‑572, 00656, 00657. Designed for high‑efficiency evaporator applications, this ECM motor delivers reliable airflow in coolers, freezers, display cases, and other commercial refrigeration systems.

Features a dual‑voltage ECM design with universal mounting options, ball‑bearing construction, and IP67 submersible protection. Ideal for replacing shaded‑pole and PSC motors with a more efficient, cooler‑running upgrade.

⚙️ Specifications

• Power Rating: 4 to 25 Watts
• Voltage: 115V / 230V (dual‑voltage, no wiring change required)
• Amperage: 0.22–0.75A @ 115V / 0.15–0.45A @ 230V
• RPM: 1550–1725 RPM
• Phase / Frequency: 1‑Phase, 50/60 Hz
• Enclosure: TEAO (Totally Enclosed Air Over)
• Rotation: CCW Opposite Shaft End (CCWOSE)
• Frame Size: 3.3" (35 Frame)
• Ambient Temp: −40°C to +55°C
• Bearings: Ball Bearing
• Protection: IP67 Submersible

Key Features

• High‑efficiency ECM design (up to 65–70% efficient)
• Universal mounting: standard 3‑hole + Hussmann 4‑hole pattern
• Thermally protected ball‑bearing system
• Dual‑voltage operation with no connection changes
• Ideal for evaporator and commercial refrigeration applications

Replaces Part Numbers

S59‑572, 00656, 00657

Upgrade your refrigeration system with this high‑efficiency ECM motor — durable, quiet, and engineered for long service life in demanding commercial environments.
