Parts for Maytag

Spark Module for Maytag, Magic Chef, AP4010034, PS2003170, 12001596

(No reviews yet) Write a Review
SKU:
12001596
UPC:
840993003110
MPN:
12001596
Condition:
New
Availability:
Restocking Frequently – Order Now Before It’s Gone
  • 12001596 - Spark Module for Maytag, Magic Chef
  • 12001596 - Spark Module for Maytag, Magic Chef
  • 12001596 - Spark Module for Maytag, Magic Chef
$18.46

Free ground shipping on orders over $35.00! Orders under $35.00 are a flat rate of $6.00! In the 48 Contiguous US States Only.



Out of stock

Frequently bought together:

Description

Spark Ignition Module | 4+0 Configuration | Replaces Maytag & Magic Chef 12001596 | OEM-Compatible

Restore reliable ignition to your cooktop with this brand-new spark module, engineered to replace Maytag/Magic Chef part number 12001596. This 4+0 configuration module powers the top burners only, delivering consistent spark performance for safe and efficient lighting.

⚙️ Product Specifications:

  • Configuration: 4+0 (4 top burners only)
  • ️ Part Number: 12001596
  • Replaces: AP4010034, 400570, 4381542, 4381588, 4381828, 74003288,
    7431P017-60, 7431P020-60, 7431P021-60, 7431P023-60, 7431P024-60, 7431P027-60,
    8189589, AH2003170, EA2003170, PS2003170
  • Condition: Brand New – Unused
  • Application: Top burner ignition only (does not support oven spark)
  • ⚠️ Voltage: Standard 120V AC input

✅ Fits Models:

Compatible with select Maytag®, Magic Chef®, and other Whirlpool-family gas ranges. Please verify your model and part number before purchase. If unsure, contact the seller with your appliance’s model number for confirmation.

Common Fixes:

  • ❌ Burners not sparking or clicking
  • No ignition despite gas flow
  • Silent cooktop when knobs are turned
  • ⚡ Intermittent or weak spark output

️ Installation Tips:

  • Disconnect power before servicing
  • Access spark module behind control panel or rear cover
  • Label and disconnect wires from old module
  • Mount new module and reconnect wires to matching terminals
  • ✅ Test burner ignition before reassembling appliance

⚠️ Installation Disclaimer:

This spark module is intended for use only with compatible gas range models. Buyer is responsible for verifying model and part number compatibility before purchase. Installation should be performed by a qualified technician. Seller is not liable for damage or injury resulting from improper installation or servicing.

Reliable ignition. OEM fit. 4-burner spark module for Maytag and Magic Chef ranges.
