Dryer PTS Relay fits Whirlpool, AP6023004, PS11756343, WPW10563095

⚡ Dryer PTS Relay | Choice Manufactured Parts (W10563095CM) | Replaces Whirlpool® WPW10563095

Restore reliable dryer start‑up performance with this brand‑new Choice Manufactured Parts PTS relay. Designed as a high‑quality replacement for Whirlpool® part number WPW10563095, this relay controls the push‑to‑start circuit, ensuring proper motor engagement and consistent dryer operation. Built to OEM‑style specifications for dependable performance.

Electrical Specifications:

• ⚡ 120V operation
• ⏱️ 50/60Hz frequency
• 10A rated current
• ️ 1/2 HP motor compatibility
• 3‑terminal relay design

Replaces Part Numbers:

AP6023004, WPW10563095, 3022058, PS11756343, W10563095
Direct replacement for Whirlpool® PTS relay W10563095.

✅ Fits Dryer Models:

7MMEDX655EW0 7MMGDC400DW0 7MMGDC400DW1 7MMGDC400DW2 7MMGDC400DW3 7MMGDX655EW0 MEDX655DW1 MEDX6STBW1 MGDX500BW0 MGDX500BW1 MGDX500BW2 MGDX655DW1 MGDX6STBW0 MGDX6STBW1 7MMGDX655EW1 YMEDX500BW1 YMEDX6STBW0 11060222511 11070222512 110C60222511 110C60242511 7MMEDX655EW1 MGDX655DW2 MGDX6STBW2 WETLV27HW0 WGTLV27HW0 YMEDX6STBW1 WETLV27HW1 11060222510 11070222510 11070222511 11070222513 11070222514 110C60222510 110C60242510 MEDX500BW0 MEDX500BW1 MEDX655DW0 MEDX6STBW0 MGDX655DW0 WETLV27HW2 WETLV27HW3 WGTLV27HW1 WGTLV27HW2 WGTLV27HW3 YMEDX500BW0

Common Fixes:

• ❌ Dryer will not start when pressing the start button
• ⚠️ Intermittent starting or clicking noises
• Replacing a burned, worn, or unresponsive PTS relay
• Dryer motor not engaging despite proper voltage

️ Installation Tips:

• Unplug dryer before servicing electrical components
• Access relay behind the control panel or rear panel (varies by model)
• Disconnect wiring harness and remove old relay
• Install new relay using the same terminal positions
• Test dryer start function before reassembling panels

⚠️ Compatibility & Safety Disclaimer:

This PTS relay is intended only for compatible dryer models listed above. Buyer is responsible for verifying model and part compatibility before purchase. Installation should follow manufacturer safety guidelines.

Restore dependable dryer start‑up performance with this OEM‑fit PTS relay replacement.
